MIL-L-45522A
DRAWINGS
U.S. Army Weapons Command
Linker-Delinker, 7.62MM, Hand: M21A1.
D7791394
-
(Product drawings referenced In this specification form a part of D7791394. )
PUBLICATIONS
U.S. Army Weapons Command
Packaging Data Sheet for Linker-Delinker,
P7791394
-
7.62MM Hand: M21A1.
Index of Inspection Equipment Lists.
IEL11013156 -
(Copies of specifications, standards, drawings, and publications required
by suppliers in connection with specific procurement functions should be
obtained from the procuring activity or as directed by the contracting
officer.)
*
3.1 First article. Requirements for submission of first article
shall be as specified in the contract (see 6.1). Unless otherwise
specified (see 6.1), the first article shall include the pilot package
(see 5.1).
3.2 Materials, construction and design. Linker-delinker shall
conform to the materials, constriction and design requirements specified
--
-
herein, on Drawing D7791394 and in MIL-W-13855.
3.2.1 Handle roller. The handle roller shall rotate without
binding on the handle.
3.2.2 Stud roller. The stud roller shall rotate without binding
on the handle stud and shall move in the camway of the bracket without
binding.
3.3 Functioning. Linker-delinkers shall operate through their
full range of travel without binding and shall be capable of linking
or delinking 21 rounds of 7.62mm ammunition in one stroke. Testing shall
be as specified in 4.5.3.2.
2
