4.5.2 .2.1.1 Bracket (Drawing C7791404).
Inspection
Categories
Defect
AQL
Method
Critical:
None defined.
None defined.
Major:
Minor:
SMTE
Physical requirement not met.
201
1.5
202
Functional roller slot undersize
1.5
visual
(.625 plug gage shall travel
freely through entire roller slot)
4.0
203
Workmanship not as specified
visual.
4.5.2.2.1.2 Linker-delinker, 7.62mm, hand: M21A1 (Drawing D7791394.
Inspection
AQL
Categories
Defect
Method
Critical:
None defined:
Major:
0.65
Visual
Missing or improperly assembled
101
parts ,
Minor:
Visual
1.5
201
Missing or defective protective
coating.
Visual
Missing or improper identification
1.5
202
markings .
Visual
Diameter plate securing holes.
1.5
203
SMTE
Improper stud torque.
1.5
204
4.0
visual
Workmanship.
205
4.5.3
Testing.
*
4.5.3.1 Failure data. All tests shall be conducted on a complete
linker-delinker.
If test requirements cited herein are not met, accept-
ance of the linker-delinker shall be deferred and the contractor shall
accomplish as applicable, the following actions:
Conduct a failure analysis study perforating a dimensional
a.
physical and visual examination of the components which are
suspected to be the cause of failure or malfunction.
